Growatt 48V 3KW 5KW Off Grid Solar Inverter

Growatt 48V 3KW 5KW Off Grid Solar Inverter

Growatt SPF-5000es is a famous off-grid inverter. It has an output voltage of 230 volts and can be configured with grid or solar input priorities. It achieves multi-stage parallel operation and supports up to 6 machines operating at the same time. It also can provide single-phase or three-phase electricity.

  • Model No :

    SPF-5000es
  • Rated Power :

    5000W
  • Weight :

    12 kg
  • Dimension :

    330/485/135mm
  • Maximum PV Array Power :

    6000W
  • Max Charge Current :

    80A
  • Maximum PV Array Open Circuit Voltage :

    450VDC

Growatt 48V 3KW 5KW Off Grid Solar Inverter

Growatt SPF-5000es is a famous off-grid inverter. It has an output voltage of 230 volts and can be configured with grid or solar input priorities. It achieves multi-stage parallel operation and supports up to 6 machines operating at the same time. It also can provide single-phase or three-phase electricity.

Growatt SPF-5000es Inverter

MODEL SPF 3500 ES SPF 5000 ES
Rated Power 3500VA/ 3500W 5000VA/ 5000W
INPUT
Voltage 230 VAC
Selectable Voltage Range 170-280 VAC:90-280 VAC
Frequency Range 50Hz/60Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt.Mode) 230VAC土5%@ 50/60Hz
Surge power 7000VA 10000VA
Transfer Time 10ms typical, 20ms Max
Wave form Pure sine wave
SOLAR CHARGER
MAX.PV Array Power 4500W 6000W
MPPT Range@ Operating Voltage 120VDC~430VDC
Maximum PV Array Open Circuit Voltage 450VDC
Maximum Charging Current 80A 100A
Maximum Efficiency 93%
PHYSICAL
Dimension.D*W*H(mm) 330/485/135mm
Net Weight (kgs)
11.5 kg 12.0 kg
OPERATING ENVIRONMENT
Humidity
5% to 95% Relative Humidity(Non-condensing)
Operating Temperature
0°C-55°C
Storage Temperature
-15°C-60°C
